Lifting Chain
Product Overview
Our lifting chain is engineered for superior performance in demanding industrial lifting operations. Crafted from premium alloy steel, these chains meet international standards such as EN 818-2, Grade 80, ensuring exceptional strength, durability, and safety. Designed for overhead lifting, towing, and rigging applications, our lifting chains provide reliable load handling capacities up to 50 tons or more, depending on configuration.
Each link in our lifting chain undergoes rigorous heat treatment processes, including quenching and tempering, to achieve high tensile strength and resistance to wear. Available in various diameters from 6mm to 34mm, these chains are ideal for use with chain hoists, cranes, and other lifting equipment. We prioritize precision manufacturing to minimize elongation under load, guaranteeing consistent performance even in harsh environments like marine, construction, and manufacturing sites.
Compliance with ISO 3077 and ASME B30.9 standards underscores the reliability of our lifting chain products. Whether you're securing heavy machinery, transporting cargo, or performing maintenance lifts, our lifting chains deliver unmatched safety and efficiency, reducing downtime and operational risks.
Key Features
- High-Grade Alloy Steel Construction: Forged from low-alloy steel for maximum tensile strength and impact resistance, ensuring the lifting chain withstands extreme loads without deformation.
- EN 818-2 Grade 80 Certification: Meets or exceeds European standards for lifting chains, with a safety factor of 4:1 for secure overhead lifting.
- Superior Wear Resistance: Advanced surface treatments like black oxide or galvanized finishes protect against corrosion, extending the service life of the lifting chain in wet or chemical-exposed conditions.
- Precise Link Dimensions: Uniform oval links with exact pitch and diameter tolerances for smooth operation in sprockets and hoists.
- High Breaking Load Capacity: Minimum breaking force exceeds 800kN for larger diameters, providing confidence in heavy-duty applications.
- Low Elongation Under Load: Engineered to maintain chain integrity, preventing dangerous stretching during lifts.
- Customizable Lengths and Configurations: Available in welded or endless loops, tailored to specific project needs.
- Traceability and Markings: Each lifting chain features laser-etched grade, batch, and manufacturer codes for full compliance and inspection ease.
- Temperature Resistance: Operational range from -40°C to +200°C, suitable for diverse industrial environments.
Technical Specifications
| Diameter (mm) | Pitch (mm) | Inside Width (min, mm) | Working Load Limit (WLL, tonnes) | Minimum Breaking Load (kN) | Weight (kg/m) | Grade |
|---|---|---|---|---|---|---|
| 6 | 18 | 7.8 | 0.63 | 31.5 | 0.79 | 80 |
| 7 | 21 | 9.1 | 0.92 | 45.0 | 1.08 | 80 |
| 8 | 24 | 10.4 | 1.24 | 59.0 | 1.40 | 80 |
| 10 | 30 | 13.0 | 2.00 | 95.0 | 2.20 | 80 |
| 13 | 39 | 16.9 | 3.37 | 160.0 | 3.80 | 80 |
| 16 | 48 | 20.8 | 5.03 | 240.0 | 5.70 | 80 |
| 18 | 54 | 23.4 | 6.41 | 305.0 | 7.20 | 80 |
| 20 | 60 | 26.0 | 8.00 | 380.0 | 8.90 | 80 |
| 22 | 66 | 28.6 | 9.68 | 460.0 | 10.70 | 80 |
| 26 | 78 | 33.8 | 13.70 | 670.0 | 15.00 | 80 |
| 32 | 96 | 41.6 | 22.00 | 1020.0 | 22.60 | 80 |
Note: Specifications are for Grade 80 lifting chain compliant with EN 818-2. Custom sizes and grades (e.g., Grade 100) available upon request. Always refer to the latest standards and perform regular inspections.
Application Scenarios
In construction and infrastructure projects, our lifting chain excels in hoisting steel beams, precast concrete elements, and heavy formwork. Its robust design ensures safe vertical and horizontal lifts on towering cranes, minimizing risks in high-altitude operations.
Within manufacturing facilities, lifting chains are integral to assembly lines for moving engines, transformers, and machinery components. Paired with electric chain hoists, they facilitate precise positioning, boosting productivity while adhering to OSHA safety protocols.
Shipping and logistics sectors rely on our lifting chains for container handling, cargo securing, and port crane operations. The corrosion-resistant finishes make them perfect for marine environments, where exposure to saltwater demands unyielding performance.
In mining and oil & gas extraction, these chains handle abrasive materials and extreme conditions, supporting dragline buckets, drilling rigs, and personnel lifts with proven reliability under dynamic loads.
Other uses include theater rigging, automotive production, and warehouse automation, where the lifting chain's versatility supports diverse rigging configurations for optimal efficiency.
Advantages
- Enhanced Safety: 4:1 safety factor surpasses industry minima, reducing accident risks and insurance premiums.
- Cost Efficiency: Longer lifespan lowers replacement frequency, delivering superior ROI compared to lower-grade alternatives.
- Versatile Compatibility: Fits standard Grade 80 hooks, slings, and hoists, simplifying integration into existing systems.
- Environmental Durability: Resists fatigue, shock loads, and chemicals, ideal for global operations in varied climates.
- Regulatory Compliance: Full traceability supports audits and certifications like CE marking and Lloyd's Register approval.
- Optimized Weight-to-Strength Ratio: Lighter than Grade 70 chains while offering higher capacities, easing handling for operators.
Why Choose Us
As a leading manufacturer of industrial lifting solutions, we bring decades of expertise in producing top-tier lifting chain products. Our state-of-the-art facilities employ automated welding and non-destructive testing (NDT) like magnetic particle inspection to ensure zero defects. Every batch undergoes proof load testing at 1.5 times WLL, guaranteeing performance from the first lift.
We hold certifications including ISO 9001, ISO 14001, and OHSAS 18001, reflecting our commitment to quality, sustainability, and worker safety. Partnerships with global leaders in crane manufacturing validate our lifting chains' reliability in real-world applications.
Our supply chain optimizes delivery times for international trade, with flexible MOQs and value-added services like custom shortening, testing certificates, and packaging. Choose us for lifting chains that prioritize your operational success and peace of mind.
FAQ
What is the difference between Grade 80 and Grade 100 lifting chain?
Grade 80 lifting chain offers a working load limit with a 4:1 safety factor, suitable for most industrial uses. Grade 100 provides higher strength (up to 25% more WLL) for specialized heavy-duty applications, both fully compliant with EN 818 standards.
How often should a lifting chain be inspected?
Visual inspections are recommended before each use and thoroughly every 6-12 months, or after exposure to shock loads. Follow ASME B30.9 guidelines, retiring chains showing wear over 10% or cracks.
Are your lifting chains suitable for overhead lifting?
Yes, our Grade 80 and higher lifting chains are specifically designed and certified for overhead lifting when used with compatible components and proper rigging techniques.
What finishes are available for corrosion protection?
Options include black oxide, galvanized (zinc-plated), and stainless steel variants, tailored to environmental demands from indoor dry settings to offshore marine exposure.
Can lifting chains be repaired if damaged?
No, damaged links must be replaced entirely. Welding repairs compromise strength; always use factory-welded assemblies for safety.
What is the maximum temperature for lifting chain operation?
Standard alloy steel lifting chains perform up to +200°C short-term; consult us for high-temperature alloys exceeding this limit.
